Machineries

List Of HMC Machines

 Manufacturer
 Model
 Table Size
 Magazine size
 X,Y & Z axes
 BFW
MPH 650
 630 x 630 mm
 60 tool
 900 x 860 x 630
 BFW
 MPH 500
 500 x 500 mm
 40 tool
 700 x 560 x 560
 BFW
 Prima 65
 800 x 630 mm
 60 tool
 1000 x 850 x 900
 BFW
 Prima 65
 800 x 630 mm
 60 tool
 1000 x 850 x 900
 Toshiba
 BMC-8B
 800 x 800 mm
 30 tool
 1000 x 800 x 800

List Of CNC Lathe Machines

 Manufacturer
 Model
 Chuck Dia
 Max Turning Length
 Quantity
 ACE Designers
Jobber XL
 200 mm
 400 mm
 1 No
 ACE Designers
Jobber XL
 200 mm
 400 mm
 1 No
 ACE Designers
Jobber LM
 200 mm
 400 mm
 1 No
 LMW
 Pilatus 15T
 200 mm
 400 mm
 1 No
 PMT
 Supercut 6
 160 mm
 600 mm
 1 No

List of Conventional machines & Equipments

  • Conventional
  • Radial Drill - 1 No.
  • Center Lathe - 1 No.
  • Pillar Drill - 1 No.
  • Bench Grinder - 1 No.
  • Hydraulic Pallet Truck & Hydraulic Stacker
  • Jib Arm Crane - with 3 tonne hoist - 1 No.
  • Air Compressors - 4 Nos
  • Air Dryers - 4 Nos
  • DG Set - 83 KV (Atlas Copco)

List of Measuring Aids

  • CMM(Co-ordinate Measuring Machine) - Zeiss make, Model Spectrum-II, X,Y,Z = 700 x 1000 x 600 mm
  • 2D Measuring Height - Mitutoyo Make, Model LH600
  • Surface Roughness Tester - Mitutoyo make, Model- ST 201P
  • Tool Presetter - Optimech Make
  • Micrometers - From Range 0 to 250 mm
  • Vernier Calipers ( Dial, Digital, normal) - From Range 0 to 500 mm
  • Bore Gauges - From Range 0 to 300 mm
  • Bench Center, Surface plates (Granite & CI), Dial stands, V Blocks etc. etc. required accessories for day to day inspection.
  • Various Thread Plug & Ring Gauges, Plain Plug & Ring Gauges, Slip Gauges, Snap Gauges etc.
  • Several types of Special Cutting Tools, Special inspection fixtures, Form cutters, Form Tools etc.
  • Jigs & Fixtures for @ 30 varieties of components.
